Product Model
SWB-214601
Description:Product model:SWB-214601 Description:Wiring Blocks, 50 Pair, without Legs
Add List
Product Description
ELECTRICAL:
1. VOLTAGE RATING: 125 VAC RMS
2. CURRENT RATING: 1.5 AMP
3. CONTACT RESISTANCE: 100 MILLIOHMS MAX
4. INSULATION RESISTANCE: 1000 MEGOHMS MIN @ 500 VDC
5. DIELECTRIC STRENGTH: 750 VAC RMS 60HZ, 1MIN
Product parameters
MATERIAL:
1. PANEL FRAME: CARBON STEEL, POWDER COATING IN BLACK COLOR
2. BASE MATERIAL: PC UL94V-0
3. CABLE BINDER MATERIAL: PC UL94V-0
4. LEG MATERIAL: PC UL94V-0
5. IDC HOUSING AND PLATE: PC UL94V-0
6.TERMINALS MATERIAL: PHOSPHOR BRONZE T=0.8mm
7.WIRE: AWG 24~26
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SWB-214601 | Wiring Blocks, 50 Pair, without Legs | 40 PCS | 40*29*53 cm | 9.65 kg |
