Product Model
SPP-2C62B1 SPP-2662L1 SPP-2662D1 SPP-2962A1 SPP-2962C1 SPP-2C62B1 SPP-2C62A1 SPP-2962B1
Product parameters
NOTES:
ELECTRICAL :
1. VOLTAGE RATING ：125 VAC RMS.
2.CURRENT RATING ：1.5 AMP
3. CONTACT RESISTANCE：20 MILLIOHMS MAX.
4. INSUL ATION RESISTANCE ：100 MEGOHMS MIN @ 500 VDC.
5. DIELECTRIC STRENGTH：750 VAC RMS 60Hz， 1MIN.
6. C6a PERMANENT LINK :CONFORM TO ANSI/TIA/EIA-568 B.2- 1
MECHANICAL ;
1. HOUSING MATERIAL:PBT
2. PANEL FRAME : ST-12,POWDER COATING IN BL ACK COLOR
3. IDC MATERIAL: PC UL94V CONTACT: PHOSPHOR BRONZE ,TIN PL ATED
4. RJ45 JACK LIFE: 750 CYCLES MIN
5. IDC LIFE: 200 TIMES MIN
6. WIRE: AWG 22- 24
7. TIA CAT6a PERM.LINK TEST: WORST PAIR NEXT MARGIN x3.0dB
8、RE TENTIVENESS OF INSERTION STRUCTURE
ENVIRONMENTAL : 50N 60+5 S
1. STORAGE:40C TO + 70"C.
2. OPERATION: -10C TO+60C.
MATES WITH MODUL .AR PLUG CONFORMING TO FCC PART 68, SUBPART F
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SPP-2662H1 | UTP Cat.5e Patch Panel , 24 Port, 110 IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2662L1 | UTP Cat.5e Patch Panel , 24 Port, LSA IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2662D1 | UTP Cat.5e Patch Panel , 24 Port, Dual USE IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2962A1 | UTP Cat.6 Patch Panel , 24 Port, 110 IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2962C1 | UTP Cat.6 Patch Panel , 24 Port, LSA IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2962B1 | UTP Cat.6 Patch Panel , 24 Port, Dual USE IDC, with back bar | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2C62A1 | UTP Cat.6A Patch Panel, 24 Port 110 IDC | 15 PCS | 53*29*32 cm | 12.8 kg |
SPP-2C62B1 | UTP Cat.6A Patch Panel , 24 Port, Dual USE IDC | 15 PCS | 53*29*32 cm | 12.8 kg |
