Product parameters
NOTES:
1.Operat ion Temperature:-40℃~+85℃.
2.Electrial Characteristics:
2.1>Rated Current:125V AC, 1. 5A@25C.
2.2>Contact Resistance:20mS Max.
2.3>Insulation Resistance: 500MS2 Min, 100V DC/min.
2.4>Voltage Proof: 1000V AC/1 minute no breakdown.
3. Mechanical Characteristics:
3.1>Insertion Force & Wi thdrawal Force: 30N Max.
3.2>Durability:750 cycles Min.
4. Env ironmental compl iance:
4.1>the products are compliant with the RoHS,and REACH etc.
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SLU3PG64M03 | UTP 6P4C Plug | 10000 PCS | 40*29*53 | 10.88 |
